2.0 IFP Coilovers

Description

Improve your GM 1500's look and ride quality with the Dirt King 2.0 IFP Series coilovers. They come preset with 2.5" of lift to level your vehicle and include a spanner wrench for easy preload adjustments, especially useful when installing aftermarket bumpers or a winch. Although these shocks don't match the full performance of the Dirt King 2.5 DCA coilovers, they substantially outperform OE shocks by offering a smoother ride over rough terrains such as washboards and potholes. In addition they provide increased wheel travel to allow for higher articulation and improved damping on large dips.

Specifications

Front Lift Height

• Standard Models:
○ Out of the Box: Provides 3" of lift (levels vehicle).
○ Max Recommended Setting: Up to 3.5" of lift.

• Trail Boss / ZR2 / AT4 / AT4X Models:
○ Out of the Box: Provides 1.5" of lift.
○ Max Recommended Setting: 1.5" of lift (Do not exceed to maintain ride quality)

Additional Specifications

• 2" hard-anodized 6061 aluminum bodies
• Internal floating piston
• Induction-hardened 5/8" shafts

*Note: Shocks must be paired with aftermarket UCAs.

What's Included

2.0 Dirt King IFP Series coilovers
Spanner wrench
All necessary mounting hardware
Installation instructions

Features

Increased suspension travel
Vehicle specific valving providing optimal ride comfort
Aluminum body for cooler operation and corrosion resistance
Direct bolt-on replacement that uses factory shock mounting location
Maxima custom oil blend. The proprietary light viscosity semi-synthetic oil blend is low friction and extremely resistant to high operating temperatures
Cold wound, high-tensile alloy steel coil springs that retain consistent rate and ride height
Completely rebuildable and serviceable. All tools and replacement parts can be purchased from Dirt King

Instructions

Compatibility

2019-2025 Chevy Silverado 1500 2WD / 4WD
2019-2025 GMC Sierra 1500 2WD / 4WD
*Requires ARC delete for models equipped with ARC (Adaptive Ride Control also know as MagneRide)
