DS18 PRO-DPL1 2" Throat Bolt On Compression Driver 2" Throat Titanium VC 640 Watts 8 ohm
Drivers are known for their extreme loudness all while maintaining the highest efficiency and decibel to wattage ratio. Ferrite is definitely a great motor structure you want to go with for the absolute loudest ear piercing high range frequencies. This ferrite driver is compatible with 4 bolt horns (throat) of all sizes. This will be an amazing addition to any system that needs super loud highs.
This driver comes with a massive 2 inch titanium voice coil that takes 160 AES and 640 Peak power for extreme decibel production backed with a high efficiency motor.
Highlights
- Ferrite motor structure that provides great motor force and loudness.
- High strength phenolic voice coil taking 160 AES watts and 640 peak watts.
- Intense high frequency volume without sacrificing sound quality.
- Compatible with all DS18 4 bolt throats giving a huge variety of mounting depths
Technical Details
SPECIFICATIONS | |
Throat Diameter | 2" / 50.8 mm |
Installation Type | Bolt on |
Nominal Impedance | 8 Ohms |
AES Power Handling | 160W |
Program Power Handling | 320W |
Peak Power Handling | 640W |
Sensitivity (1w/1m) | 109dB |
Frequency Response | 630Hz-20KHz |
Recommended Hi Pass Crossover | 900 Hz |
MOTOR | |
Voice Coil Diameter | 2.03" / 51.5mm |
VC Former Material | Kapton |
Winding Material | CCA |
Diaphragm Material | Titanium |
Magnet Material | Ferrite |
Magnet Weigh | 35 Oz |
Body Material | Plastic Cover |
MEASUREMENTS | |
Overall Diameter | 5.27" / 134mm |
Overall Depth | 2.4" / 61mm |
Bolt Pattern - Type | 4" / 102mm - M6 |


- Regular price
- $59.95
- Regular price
- $59.95
DS18 PRO-DPL1 2" Throat Bolt On Compression Driver 2" Throat Titanium VC 640 Watts 8 ohm
Drivers are known for their extreme loudness all while maintaining the highest efficiency and decibel to wattage ratio. Ferrite is definitely a great motor structure you want to go with for the absolute loudest ear piercing high range frequencies. This ferrite driver is compatible with 4 bolt horns (throat) of all sizes. This will be an amazing addition to any system that needs super loud highs.
This driver comes with a massive 2 inch titanium voice coil that takes 160 AES and 640 Peak power for extreme decibel production backed with a high efficiency motor.
Highlights
- Ferrite motor structure that provides great motor force and loudness.
- High strength phenolic voice coil taking 160 AES watts and 640 peak watts.
- Intense high frequency volume without sacrificing sound quality.
- Compatible with all DS18 4 bolt throats giving a huge variety of mounting depths
Technical Details
SPECIFICATIONS | |
Throat Diameter | 2" / 50.8 mm |
Installation Type | Bolt on |
Nominal Impedance | 8 Ohms |
AES Power Handling | 160W |
Program Power Handling | 320W |
Peak Power Handling | 640W |
Sensitivity (1w/1m) | 109dB |
Frequency Response | 630Hz-20KHz |
Recommended Hi Pass Crossover | 900 Hz |
MOTOR | |
Voice Coil Diameter | 2.03" / 51.5mm |
VC Former Material | Kapton |
Winding Material | CCA |
Diaphragm Material | Titanium |
Magnet Material | Ferrite |
Magnet Weigh | 35 Oz |
Body Material | Plastic Cover |
MEASUREMENTS | |
Overall Diameter | 5.27" / 134mm |
Overall Depth | 2.4" / 61mm |
Bolt Pattern - Type | 4" / 102mm - M6 |
