DS18 HYDRO NXL-F4 Flush Mount Class D Full-Range Marine 4-Channel Boat, ATV, UTV Amplifier with Voltmeter 1200 Watts

The F4 is an exact duplicate of the very popular NXL-400.4 but now offered in flat mount configuration so you can keep a flush and clean look to your install. This 4 channel amplifier is the go to source to power all your DS18 marine speakers as all are an amazing fit with this sleek and powerful hydro amp.

Highlights
  • Flush / Flat mount design so you can keep your install looking clean and flush.
  • Great to power all DS18 NXL series speakers with great loudness and efficiency.
  • Full Range configuration so it can be used for virtually any speaker within its power recommendations.
    Technical Details
    NXL-F4 Product Manual

    Power Output @ 2 ohms 160Wx4CH
    Power Output @ 4 ohms 100Wx4CH
    Bridge Power Output @ 4 ohms 320Wx2CH
    Total Harmonic Distortion <0.1%
    S/N Ratio Red 1W @ 4 ohms 90dB
    Gain Range 0.2-6V
    Crossover Range 40 - 400Hz
    Frequency Range 20Hz - 20KHz
    Bass Boost 0-18dB (Rear CHs)
    Forced Cooling System N/A
    Bass Remote Control N/A
    Topology Operation Full Range Digital
    Dimensions (MM) 238 x 135 x 41


      NXL 4-Channel Full-Range Class D IP67 Marine and Powersports Flush Mount Amplifier 4 x 100 Watts Rms @ 4-Ohm

      SKU NXL-F4
      $527.95
      $527.95

      DS18 HYDRO NXL-F4 Flush Mount Class D Full-Range Marine 4-Channel Boat, ATV, UTV Amplifier with Voltmeter 1200 Watts

      The F4 is an exact duplicate of the very popular NXL-400.4 but now offered in flat mount configuration so you can keep a flush and clean look to your install. This 4 channel amplifier is the go to source to power all your DS18 marine speakers as all are an amazing fit with this sleek and powerful hydro amp.

      Highlights
      • Flush / Flat mount design so you can keep your install looking clean and flush.
      • Great to power all DS18 NXL series speakers with great loudness and efficiency.
      • Full Range configuration so it can be used for virtually any speaker within its power recommendations.
        Technical Details
        NXL-F4 Product Manual

        Power Output @ 2 ohms 160Wx4CH
        Power Output @ 4 ohms 100Wx4CH
        Bridge Power Output @ 4 ohms 320Wx2CH
        Total Harmonic Distortion <0.1%
        S/N Ratio Red 1W @ 4 ohms 90dB
        Gain Range 0.2-6V
        Crossover Range 40 - 400Hz
        Frequency Range 20Hz - 20KHz
        Bass Boost 0-18dB (Rear CHs)
        Forced Cooling System N/A
        Bass Remote Control N/A
        Topology Operation Full Range Digital
        Dimensions (MM) 238 x 135 x 41
